When doing replacement or upgrading on 1996 – 2018 Toyota RAV4 Base EV LE Limited Sport XLE capsule fog halogen headlamps lamps with without, the bulb size guide is necessary for you to take the reference.
Jump to corresponding car model with the catalog bellow.

Low Beam Headlight 2015 9005
1998 – 2000, 2006 – 2011 9006
High Beam Headlight 1998 – 2000, 2006 – 2011, 2015 9005
High Beam and Low Beam Headlight 1996 – 1997, 2004 – 2005 9003
Front Fog Light 2004 – 2005 9006
2006 – 2011, 2015 H8/H11/H16
Back Up Light 1996 – 1997 1156
1998 – 2000 7440
2004 – 2011, 2015 921
Brake 1996 – 1997 1157
1998 – 2000, 2004 – 2005, 2015 7443
Daytime Running Light 2015 9005
Dome Light 1996 – 2000, 2004 – 2011, 2015 DE3175
Front Side Marker 1998 – 2000, 2015 168
1996 – 1997, 2004 – 2005 194
2006 – 2011 7443
Front Turn Signal 1996 – 1997 1157
2004 – 2005 7440
2006 – 2011 7443
2015 7443NA
License Plate 1996 – 2000, 2004 – 2011, 2015 168
Parking Light 1996 – 1997 1157
1998 – 2000 1157NA
2004 – 2005 168
2006 – 2011 7443
2015 7444NA
Rear Side Marker 1996 – 2000, 2006 – 2011 194
2015 7443
Rear Turn Signal 1996 – 1997 1156
1998 – 2000, 2004 – 2005, 2015 7440
2006 – 2011 7440NA
Tail Light 1996 – 1997 1157
1998 – 2000, 2004 – 2005 7443
Front Inner Turn Signal 1998 – 2000 1157NA
Front Outer Turn Signal 1998 – 2000 194
Luggage Compartment 2006 – 2011 DE3022
2015 DE3175
Center High Mount Stop Light 1998 – 2000, 2004 – 2005 7440
1996 – 1997 921
Glove Box 1996 – 1997 74
Inner Tail Light 2015 194
Map Light 2015 168
2004 – 2005 DE3175
Outer Tail Light 2015 7443
High Beam and Low Beam Headlight 2001 – 2003 9003
Front Fog Light 2001 – 2003 9006
Back Up Light 2001 – 2003 7440
Brake 2001 – 2003 7443
Dome Light 2001 – 2003 DE3175
Front Side Marker 2001 – 2003 194
Front Turn Signal 2001 – 2003 7440
License Plate 2001 – 2003 168
Parking Light 2001 – 2003 168
Rear Turn Signal 2001 – 2003 7440
Tail Light 2001 – 2003 7443
Center High Mount Stop Light 2001 – 2003 7440
Map Light 2001 – 2003 DE3175
High Beam and Low Beam Headlight 2001 – 2003 9003
Back Up Light 2001 – 2003 7440
Brake 2001 – 2003 7443
Dome Light 2001 – 2003 DE3175
Front Side Marker 2001 – 2003 194
Front Turn Signal 2001 – 2003 7440NA
License Plate 2001 – 2003 168
Parking Light 2001 – 2003 168
Rear Turn Signal 2001 – 2003 7440
Tail Light 2001 – 2003 7443
Center High Mount Stop Light 2001 – 2003 7440
Map Light 2001 – 2003 DE3175
High Beam and Low Beam Headlight 2016 – 2018 9012
Front Fog Light 2016 – 2018 H8/H11/H16
Back Up Light 2016 – 2018 921
Brake 2016 – 2018 7443
Daytime Running Light 2016 – 2018 9012
Dome Light 2016 – 2018 DE3175
Front Side Marker 2016 – 2018 168
Front Turn Signal 2016 – 2018 7443NA
License Plate 2016 – 2018 168
Parking Light 2016 – 2018 7444NA
Rear Side Marker 2016 – 2018 7443
Rear Turn Signal 2016 – 2018 7440NA
Luggage Compartment 2016 – 2018 168
Inner Tail Light 2016 – 2018 194
Map Light 2016 – 2018 168
Outer Tail Light 2016 – 2018 7443
Low Beam Headlight 2013 – 2014 9005
2012 9006
High Beam Headlight 2012 – 2014 9005
Front Fog Light 2012 – 2014 H8/H11/H16
Back Up Light 2012 – 2014 921
Brake 2013 – 2014 7443
Daytime Running Light 2013 – 2014 9005
Dome Light 2012 – 2014 DE3175
Front Side Marker 2013 – 2014 168
2012 7443
Front Turn Signal 2012 7443
2013 – 2014 7443NA
License Plate 2012 – 2014 168
Parking Light 2012 7443
2013 – 2014 7444NA
Rear Side Marker 2012 194
2013 – 2014 7443
Rear Turn Signal 2013 – 2014 7440
2012 7440NA
Luggage Compartment 2012 DE3022
2013 – 2014 DE3175
Inner Tail Light 2013 – 2014 194
Map Light 2013 – 2014 168
Outer Tail Light 2013 – 2014 7443
Low Beam Headlight 2012 9006
High Beam Headlight 2012 9005
Front Fog Light 2012 H8/H11/H16
Back Up Light 2012 921
Dome Light 2012 DE3175
Front Side Marker 2012 7443
Front Turn Signal 2012 7443
License Plate 2012 168
Parking Light 2012 7443
Rear Side Marker 2012 194
Rear Turn Signal 2012 7440NA
Luggage Compartment 2012 DE3022
Low Beam Headlight 2012 9006
High Beam Headlight 2012 9005
Front Fog Light 2012 H8/H11/H16
Back Up Light 2012 921
Dome Light 2012 DE3175
Front Side Marker 2012 7443
Front Turn Signal 2012 7443
License Plate 2012 168
Parking Light 2012 7443
Rear Side Marker 2012 194
Rear Turn Signal 2012 7440NA
Luggage Compartment 2012 DE3022
High Beam Headlight 2012 – 2014 9005
Back Up Light 2012 – 2014 921
Dome Light 2012 – 2014 DE3175
Front Side Marker 2012 – 2014 3457
Front Turn Signal 2012 – 2014 3457NA
License Plate 2012 – 2014 168
Parking Light 2012 – 2014 3357NA
Rear Side Marker 2012 – 2014 194
Rear Turn Signal 2012 – 2014 7440NA
Luggage Compartment 2012 – 2014 DE3022
Low Beam Headlight 2013 – 2014 9005
High Beam Headlight 2013 – 2014 9005
Front Fog Light 2013 – 2014 H8/H11/H16
Back Up Light 2013 – 2014 921
Brake 2013 – 2014 7443
Daytime Running Light 2013 – 2014 9005
Dome Light 2013 – 2014 DE3175
Front Side Marker 2013 – 2014 168
Front Turn Signal 2013 – 2014 7443NA
License Plate 2013 – 2014 168
Parking Light 2013 – 2014 7444NA
Rear Side Marker 2013 – 2014 7443
Rear Turn Signal 2013 – 2014 7440
Luggage Compartment 2013 – 2014 DE3175
Inner Tail Light 2013 – 2014 194
Map Light 2013 – 2014 168
Outer Tail Light 2013 – 2014 7443
Low Beam Headlight 2013 – 2014 9005
High Beam Headlight 2013 – 2014 9005
Front Fog Light 2013 – 2014 H8/H11/H16
Back Up Light 2013 – 2014 921
Brake 2013 – 2014 7443
Daytime Running Light 2013 – 2014 9005
Dome Light 2013 – 2014 DE3175
Front Side Marker 2013 – 2014 168
Front Turn Signal 2013 – 2014 7443NA
License Plate 2013 – 2014 168
Parking Light 2013 – 2014 7444NA
Rear Side Marker 2013 – 2014 7443
Rear Turn Signal 2013 – 2014 7440
Luggage Compartment 2013 – 2014 DE3175
Inner Tail Light 2013 – 2014 194
Map Light 2013 – 2014 168
Outer Tail Light 2013 – 2014 7443
